MONEL K500 fasteners are alloy-based components composed of a blend of nickel and copper, augmented with iron and manganese. This versatile metal exhibits commendable mechanical properties coupled with exceptional corrosion resistance. Monel K500 Fasteners also boast resistance to various acids and alkalis, rendering them well-suited for marine environments and other corrosive applications.
MONEL K500 fasteners find extensive use across various industries, including oil refineries, chemical plants, marine applications, and nuclear power plants. Monel K500 Nuts are integral components in a wide array of equipment ranging from pumps and valves to pipelines and heat exchangers, owing to their remarkable strength and durability even under high temperatures or corrosive environments. The exceptional corrosion resistance of this alloy renders it particularly suitable for outdoor applications such as bridges or structures requiring protection from harsh weather conditions. Additionally, a range of Monel Fasteners are available, including Monel 400 Fasteners, Monel 400 Nuts, and more, catering to diverse industrial needs.
Standard MONEL alloy K - 500 Fasteners specifications as per Fasteners manufacturers.
| Material | MONEL K500 |
| Specification | IS/BS/ASTM |
| Standards | ASTM B865-04 |
| Size | 3 mm to 200 mm |
| Length | M02 to M30 |
Each MONEL alloy K - 500 Fasteners have unique design each of them are used in specific applications. Some of them are mentioned below.
Note that this chart includes only some of the most common sizes of MONEL alloy K - 500 Bolt. There are many other sizes available as well, and some applications may require custom sizes or special configurations.
Nickel (Ni)
63.00 min
Iron (Fe)
0.5 – 2
Manganese (Mn)
1.5 max
Silicon (Si)
0.50 max
Carbon (C)
0.25 max
Sulfur (S)
0.010 max
Copper (Cu)
27.00 – 33.00
| Density | 8.44 g/cm3 |
| Melting Point | 1350 °C (2460 °F) |
| Tensile Strength | Psi – 160000 , MPa – 1100 |
| Yield Strength (0.2%Offset) | Psi – 115000 , MPa – 790 |
| Elongation | 20 % |
Choose K.C. Impex for your bolt needs and experience the difference quality, expertise, and commitment can make in your projects. Contact us today to discuss your requirements, request a quote, or place an order. Join countless satisfied customers who rely on K.C. Impex for premium bolts and exceptional service.
K. C. Impex: Your top source for high-quality fittings, fasteners, nuts, bolts, and washers in high-performance alloys. With a decade of expertise, we deliver excellence, reliability, and prompt service to meet your engineering needs.
